PLAXIS 3D Tutorial 08: Dynamic analysis of a generator on an elastic foundation




Application PLAXIS 3D
Version PLAXIS 3D CONNECT Edition V21.01
PLAXIS 3D 2024.1
PLAXIS 3D 2024.2
Date created 04 Oct 2018
Date modified 21 August 2024

In this tutorial, the influence of a vibrating source on its surrounding soil is studied. To reduce the calculation time, only one-quarter of the overall geometry is modelled, using symmetry boundary conditions along the lines of symmetry. The physical damping due to the viscous effects is taken into consideration via Rayleigh damping. Also, due to radial wave propagation, 'geometric damping' can be significant in attenuating the vibration.

The modelling of the boundaries is one of the key points in the dynamic calculation. In order to avoid spurious wave reflections at the model boundaries (which do not exist in reality), special conditions have to be applied in order to absorb waves reaching the boundaries.

This exercise requires a PLAXIS 3D Ultimate license for transient groundwater flow calculations.

The attached *.log file contains all the commands to generate the model. With a Bentley Geotechnical SELECT Entitlement [GSE] licence, you can use the commands runner to open the *.log file and to execute all commands in one go, see also this instruction.
